AR0821CS image sensor delivers in challenging light conditions

Thu, Oct 07, 2021

The AR0821CS image sensor from ONsemi provides high-quality images in challenging lighting conditions. These applications include scanners and/or readers, machine-vision cameras, high-end drones, dashboard cameras, and smart building surveillance/security systems.

The AR0821CS delivers 4K video with 8.3 MP resolution at 60 fps while consuming low power. The advanced sensor includes a 2.1 micro-Ohmn DR−Pix backside illuminated (BSI) pixel design exclusive to ONsemi, which enables high-quantum efficiency, as well as on-chip HDR (eHDR) technology that delivers dynamic range in excess of 140 dB.

A high-quality pixel design delivers detailed images even in bright daylight or low light conditions. With multiple subsampling modes, the AR0821CS optimises the amount of data transmitted to provide images at a faster rate as needed by the intended application.

The AR0821CS is supported by the AP1302 co-processor and by image signal processor (ISP) and system-on-chip (SoC) devices from ONsemi technology partners. The DevSuite software provides an integrated platform to develop AR0821CS-based camera systems. Within the DevSuite software, ONsemi provides custom firmware to enable system developers to complete their camera designs with minimal effort.

Alongside ONsemi development resources, the AR0821CS has been designed into Basler’s dart family of area scan camera modules. The dart camera series enables a wide range of image processing applications and offers the latest machine vision technology in a small format.

“The integration of the new AR0821CS sensor from ONsemi into our dart camera family is a significant step toward having a superior solution component for customer projects with HDR requirements. We have already noticed that the high-performance sensor is important for the successful implementation of new applications in light-sensitive conditions,” said Malene Fricke, head of module business at Basler.

The AR0821CS is now in production and is available through local ONsemi sales support and authorised distributors.

With a focus on automotive and industrial end-markets, ONsemi is accelerating change in megatrends such as vehicle electrification and safety, sustainable energy grids, industrial automation, and 5G and cloud infrastructure.

For more information go to https://www.onsemi.com

> Read More

ST and Rosenberger unite to develop high-speed contactless connector based on 60GHz wireless technology

Wed, Oct 06, 2021

STMicroelectronics and Rosenberger, a leading manufacturer of impedance-controlled and optical connectivity solutions, are to collaborate on a contactless connector for ultra-reliable, short-range, point-to-point full-duplex data exchanges in industrial and medical applications.

Rosenberger’s RoProxCon, leverages ST’s 60GHz RF transceiver, the ST60A2, to deliver high-speed data transmission while providing immunity to movement, vibration, rotation and contaminants such as moisture and dust, which can disrupt conventional pin-and-receptacle interconnects.

The STMicroelectronics ST60A2 offers reliable, point-to-point, high-data-rate transmission of up to 6.25 Gbps over distances of a few centimetres at low power. The new connector will suit applications in smart factories, medical technology, connected devices, office equipment, conveyer technology and renewable energies.

Operating over an extended temperature range of -40 to +105 degrees C, the chip ST60A2 is suited to industrial markets. With a 2.2 x 2.2 mm package footprint, the chip offers an ultra-low power consumption of 70mW for a reliable, completely contactless link.

“Pairing ST’s contactless connectivity technology with our interconnect expertise and antenna-design knowledge enabled us to create a first-of-its-kind module that transmits full duplex data at up to 6 Gbps with complete rotational freedom,” said Folke Michelmann, executive vice-president medical and industries at Rosenberger.

“In working with ST, we see limitless application possibilities for our connector, which provides high-reliability and high-throughput at low power.”

STMicroelectronics RF&Communications division general manager Laurent Malier said: “We developed the ST60A2 contactless transceiver to allow customers to create reliable, high data-rate, extremely power-efficient wireless links. Rosenberger’s expertise in interconnects combined with our RF chip is an outstanding example of the value of the technology.”

“Customers across the full range of electronics applications have expressed interest in this transceiver and several have shared their need for a module that includes the antenna.”

Rosenberger’s portfolio includes solutions in high-frequency, high-voltage, and fibre optic technology for mobile communication networks, data centres, test and measurement applications, automotive electronics as well as for high-voltage contact systems, medical electronics an aerospace engineering.

As independent device manufacturer, STMicroelectronics works with more than 100,000 customers and thousands of partners to design and build products, solutions and ecosystems that address their challenges and opportunities, and the need to support a more sustainable world.

For more information go to http://www.rosenberger.com and http://www.st.com

> Read More

R&S FSPN offers dedicated phase noise analysis and VCO testing

Wed, Oct 06, 2021

For high speed, real-time phase noise measurements using sources that require high stability in demanding applications, the new R&S FSPN phase noise analyser and VCO from Rohde & Schwarz offers sensitivity, accuracy and reliability.

Rohde & Schwarz designed the new R&S FSPN phase noise analyser and VCO tester for production and design engineers who characterise sources such as synthesizers, VCOs, OCXOs, and DROs. Providing high sensitivity and measurement speed, the R&S FSPN suits demanding phase noise and VCO analysis in development and production.

The R&S FSPN comes in two models, one covers the frequency range from 1 MHz to 8 GHz and the other from1 MHz to 26.5 GHz, addressing radar and satellite applications in the C band, X band, Ku band, and the complete K band.

Catering to measurement challenges in these fields, the R&S FSPN expands the Rohde & Schwarz phase noise product portfolio which already contains the R&S FSWP phase noise spectrum and signal analyser.

The R&S FSPN shares R&S FSWP features such as low noise internal local oscillators coupled with real-time cross correlation engines for increased measurement sensitivity.

Cross-correlation sensitivity gains can be viewed in real-time in result traces, allowing users to adjust the trade-off between measurement speed and sensitivity to meet their application requirements.

Users in production need just a few correlations to measure high-quality oscillators, synthesizers or VCOs with high throughput. By increasing the number of correlations, users in research and development can characterise the most sensitive commercially available synthesisers and oscillators. Simultaneous device frequency and phase settling times can be measured with up to 8 GHz of real-time analysis bandwidth.

To investigate oscillator long-term frequency stability, the R&S FSPN calculates the Allan variance in the time domain at fixed intervals and uses phase noise measurements to apply cross-correlations and suppress spurs.

The analyser is also equipped with three ultra-low-noise DC sources to supply and sweep VCOs. The built-in VCO characterisation measurement mode analyses VCO characteristics such as frequency, sensitivity, RF power or current draw versus tuning voltage.

For more information go to https://www.rohde-schwarz.com/product/fspn

> Read More

OKW boosts enclosure range with larger sizes

Wed, Oct 06, 2021

OKW has added four sizes to its EasyTec range of fast-mount flanged enclosures. The new larger sizes suit more complex applications that require extra installation volume, such as IT network technology and smart factory sensor equipment.

These flanged enclosures are said to offer good stability. The flat base has a curved recess for secure pole mounting. Integrated mounting lugs feature apertures for cable ties and holes for panhead screws and there is a soft contoured top.

Internal screw pillars in the top and base enable EasyTec to accommodate two PCBs. Tamperproof stainless steel Torx assembly screws suit the housings to medical electronics.

EasyTec can be mounted quickly and easily on poles or flat surfaces in challenging industrial environments – either indoors or outdoors. Applications include IoT/IIoT, sensor systems, security and monitoring, stock control, environmental, medical and laboratory technology.

The enclosures come in four plan sizes, the original 80 and 100 and now 125 and150. Each plan size comes in two heights, giving a range of eight sizes from 101 x 50 x 22 mm to 172 x 93 x 46 mm. The enclosures are moulded from tough and UV-stable ASA+PC-FR (UL 94 V-0) in off-white (RAL 9002) as standard.

Prices start at £16. Accessories include IP 65 seals, 2.5 x 6 mm self-tapping screws (PZ1 and Torx T8) and a Torx T8 screwdriver.

Customising options include CNC machining, lacquering, printing/laser marking of legends and logos, EMC shielding, installation and assembly.

For more information go to https://www.okw.co.uk/en/Plastic-enclosures/Easytec.htm

> Read More
